Material & Passenger Hoist
GEDA 500 Z/ZP
GEDA 1500 Z/ZP
The transport platform GEDA 1500 Z/ZP unites two different machines in one, hoist for materials with a load bearing capacity of 2000kg and a transport platform for material and persons. The GEDA 1500 Z/ZP may transport 7 people in addition to 800kg of goods as soon as it has been switched to the operating mode “transport platform“. The load platforms provide enough space for bulky and heavy building materials.
GEDA 1500 Z/ZP | |
Cargo | Material/Personnel |
Load Capacity | 2000KG |
Lifting Height | 100m |
Lifting Speed | 12 m/min / 24 m/min |
Power Supply | 2 x 3 kW / 6.1 kW / 400 V / 50 Hz / 32 A |
Platform Dimension | 1.45m x 1.65m / 1.65m x 2.9m / 3.3m x 1.45m |
ELECTROELSA EHPM 2500/15
The EHPM2500/15 is also a single mast transport platform with a load capacity of 2,000kg and a operating speed of 12 metres per minute. This model offers flexibility to change the size of platform required which is suited to locations of limited space.
ELECTROELSA EHPM 2500/15 | |
Cargo | Material/Personnel |
Load Capacity | 2000KG |
Lifting Height | 220m |
Lifting Speed | 12 m/min |
Power Supply | 380/415 V / 50/60 Hz / 25 A |
Platform Dimension | 2.28m x 1.34m / 3.00m x 1.34m / 4.00m x 1.34m |
Electroelsa EHPM 1000 MINI
Electroelsa EHPM 1000 MINI | |
Cargo | Material/Personnel |
Load Capacity | 1000KG |
Lifting Height | 160m |
Lifting Speed | 12 m/min |
Power Supply | 380/415 V / 50/60 Hz/ 16 A |
Platform Dimension | 1.38m x 1.00m / 1.58m x 1.20m / 2.08m x 1.40m |
GEDA ERA 1200 Z/ZP
GEDA ERA 1200 Z/ZP | |
Cargo | Material/Personnel |
Load Capacity | 1500KG |
Lifting Height | 150m |
Lifting Speed | 12/24 m/min |
Power Supply | 1.9 kW / 400 V / 50 Hz / 16 A |
Platform Dimension | 2 x 3,0/6,1 kW/400 V/50 Hz/32 A |
SCANCLIMBER MTP 2000
SCANCLIMBER MTP 2000 | |
Cargo | Material/Personnel |
Load Capacity | 2000KG |
Lifting Height | 100m |
Lifting Speed | 12 m/min / 24 m/min |
Power Supply | 2 x (3.8/7.5) kw /400 V / 50 Hz / 63 A / 5P |
Platform Dimension | 1.1m x 1.5m x 3.0m |
ALBA PTB 3800 – 2V
ALBA PTB 3800 – 2V | |
Cargo | Material/Personnel |
Load Capacity | 3800KG |
Lifting Height | 250m |
Lifting Speed | 12 m/min / 22 m/min |
Power Supply | 30 kW / 380÷460 V – 50/60Hz / 50A |
Platform Dimension | 2.28m x 1.34m / 3.00m x 1.34m / 4.00m x 1.34m |
